Phamaceutical

Tube/Hose for Pharmaceutical, Medicine Production and Medical Industry
General Information

In case you are looking for a tube/hose for pharmaceutical and medical applications, HAKKO will be able to offer a solution for medical applications. However, please note that based on our current company business domain, we do not provide tubing/hose products for human body applications (such as catheter).

Application Examples:

(A) Medicine Coating
When the medical tablet is produced, the tablet is usually coated by sugar. In this coating process, a mixture of ingredients (such as sugar and additives) is added. In this process, HAKKO Flexible Fluorine (ETFE) Resin Yarn Reinforced Hose [E-SJB] and Flexible Fluorine (ETFE) Resin SUS Spring Hose [E-SJSP] have been used. In some cases, products with Ferrule fittings and Electrolytic Polishing (EP) are adopted for higher sanitation levels.

(B) Anti-Itch Cream
In the process of manufacturing anti-inch cream, HAKKO Flexible Fluorine (ETFE) Resin SUS Spring Hose [E-SJSP] has been adopted. This is because an inner layer is made of ETFE fluorine, showing higher levels of non-adhesiveness, leading to easy flow (non-stickiness) and high levels of sanitation.

(C) Medical Gas Hose
When you enter into a hospital room, you might see various colors of hose. HAKKO can offer hoses for this application. In fact, each country has its own regulation in terms of hose color for fluids (Medical Air, Nitrogen, Nitrous Oxide and Oxygen). Moreover, each country has its own criteria such as ISO 5359 and conductivity (anti-static) requirements.

Usually, the medical gas hose is made of PVC materials and its common I.D. is 6mm or 1/4″. HAKKO can meet various kinds of demands (color and requirements’ request) for medical gas hose.

(D) Dental Unit Chair Equipment
When you enter into a dental clinic, you will be asked to sit on a dental unit chair. There are air and water supply lines inside the dental unit chair. HAKKO can provide a soft, very small made-to-order size (and color) tube for air and water supply. For more information on this application, please visit this webpage (“Dental Unit Chair Equipment”).

*If you are interested in our Made-to-Order Offer (such as special size, color, cleanroom packing and anti-static offer), please fill out the following form.

Major Product List

Standard Product

Flexible Fluorine (ETFE) Resin Tubing Clear [Model Number: E-SJ]

image-E-SJ-mm01

E-SJ-mm

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Low Odor
Food-Sanitation
Flexibility
Transparency
Oil-Proof
Cold Resistance
Alcohol Resistance

Inner Diameter : 2 - 8mm

Flexible Fluorine (ETFE) Resin Tubing Clear Blue [Model Number: E-SJ-CBU]

image-E-SJ-CBU01

E-SJ-CBU

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Low Odor
Food-Sanitation
Flexibility
Oil-Proof
Cold Resistance
Alcohol Resistance

Inner Diameter : 2 - 8mm

Flexible Fluorine (ETFE) Resin Tubing (Ultra Soft Type) [Model Number: E-SJUS]

image-E-SJUS01

E-SJUS

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Food-Sanitation
Flexibility
Oil-Proof
Cold Resistance
Alcohol Resistance
Ultra Soft

Inner Diameter : 2 - 8mm & 1/8" - 1/4"

Flexible Fluorine (ETFE) Resin Yarn Reinforced Hose [Model Number: E-SJB]

image-E-SJB01

E-SJB

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Low Odor
Food-Sanitation
Pressure-Proof
Transparency
Oil-Proof
Cold Resistance
Alcohol Resistance

Inner Diameter : 9 - 38mm

Flexible Fluorine (ETFE) Resin SUS Spring Wire Hose [Model Number: E-SJSP]

image-E-SJSP01

E-SJSP

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Low Odor
Food-Sanitation
Vacuum
Transparency
Oil-Proof
Hard to Break
Cold Resistance
Alcohol Resistance

Inner Diameter : 12 - 38mm

Flexible Fluorine (ETFE) Resin Yarn Reinforced Hose with Ferrule Fittings [Model Number: E-SJB-F]

image-E-SJB-F01

E-SJB-F

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Low Odor
Food-Sanitation
Pressure-Proof
Transparency
Oil-Proof
Alcohol Resistance

Inner Diameter : 19 - 38mm

Flexible Fluorine Resin (ETFE) SUS Spring Wire Hose with Ferrule Fittings [Model Number: E-SJSP-F]

image-E-SJSP-F01

E-SJSP-F

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Low Odor
Food-Sanitation
Vacuum
Transparency
Oil-Proof
Hard to Break
Alcohol Resistance

Inner Diameter : 19 - 38mm

Ferrule Fittings (Swage Type) with Electrolytic Polishing

image-Ferrule-Fitting-EP01

Ferrule-Fitting-EP

Solvent Resistance
Non-Adhesiveness
Chemical Resistance
Low Elution
Low Odor
Food-Sanitation
Sanitary Fittings
Washability
Band-less Joints
RoHS 2 Free

Inner Diameter : 19 - 38mm

Made-to-Order Product

Flexible Fluorine (ETFE) Resin Tubing Anti-Static Type [Model Number: SJ-AST]

image-SJ-AST01

SJ-AST

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Flexibility
Washability
Transparency
Oil-Proof
Prevention of Static Charge

Inner Diameter :

Flexible Fluorine (ETFE) Resin Tubing (Cleanroom Package Type) [Model Number: SJ-CLT]

image-SJ-CLT01

SJ-CLT

Solvent Resistance
Non-PVC
Non-Adhesiveness
Chemical Resistance
Low Elution
Low Odor
Flexibility
Transparency
Alcohol Resistance

Inner Diameter : 2 - 8 mm & 1/8" - 1/4"

Pump Tubing (Styrene Type) [Model Number: PST]

image-PST01

PST

Non-PVC
Chemical Resistance
Low Elution
Food-Sanitation
Flexibility
Non-Phthalic Acid
Liquor and Alcool
Alcohol Resistance
RoHS 2 Free
FDA Compliant

Inner Diameter : 2 - 4mm
